Grinding Impeller for Mission 2500 Supreme Centrifugal Pump

Description

Sandman™ manufactures Mission 2500 Supreme type centrifugal pump grinding impeller H2524-XX-30

The Mission 2500 Supreme

Fluid end parts available with Supreme Hard material that has a 400 Brinell hardness. The standard impeller, casing wear pad and stuffing box are Ductile Iron to ensure even wear characteristics.
Casing provided with replaceable casing wear pad on 4x3x13 – 10x8x14 models.

Design Features:

• Versatile stuffing box
• Thick, strong, concentric casing with replaceable casing wear pad
• Casing gasket receded for protection.
• Replaceable stuffing box cover with dual stuffing box bolts
• Long-life, no-adjustment mechanical seal available for near zero leakage
• Replaceable shaft sleeve
• Solid Frame base
• Labyrinth seals for maximum bearing protection
• Duplex angular contact bearings
• Full pipe diameter entrance for minimum turbulence and maximum efficiency
• Wide semi-open impeller creates lower axial thrust for improved bearing life
• All sizes feature the same power end

Replacement Halco 2500 Centrifugal Pump

1A H10399-46-1 GASKET, CASING FIBER
1B H3932-61 NUT, CASING STUDS STAINLESS, 3/4-10 HEX HEAD
1C H2507-3 STUD, CASING STEEL, 3/4-10 X 3-1/4″ LONG
1CA H3862-76 STUD, CASING STEEL, 3/4-10 X 3″ LONG
2A H19110-72 SEAL, IMPELLER VITON
3 H22223-01-30A STUFFING BOX COVER, SEAL HARD IRON
3 H20614-01-30A STUFFING BOX COVER, PACKED HARD IRON
3A H3861-117 BOLT, STUFFING BOX STEEL, 1/2-13 X 1-1/4″
4 H20622A GLAND SET 300 STAINLESS STEEL
5 H8264-24-1A PACKING 5 RINGS & LANTERN RING GRAPHITE ASBESTOS
5A H2537-24A
