Digital Audio Processor
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Digital Audio Processor
GONSIN audio digital signal processor adopts the fourth generation audio DSP chip, hence now it is equipped with strong DSP processing power. Furthermore, the unique core DSP method and the
design for lower noise as well as lower distortion provide high-quality sound quality to the site. The updated Digital Audio Processor not only meets the operating requirements of professional
audio projects of all sizes, but also meets the application requirements of various social occasions (Theatre, concert hall, remote video conference, stadium, church, convention center, theme park,
etc.)
Features of Digital Audio Processor GX-DSP1022 / GX-DSP1023 / GX-DSP1024 / GX-DSP1025 / GX-DSP1026 / GX-DSP1022A / GX-DSP1023A / GX-DSP1024A / GX-DSP1025A / GX-DSP1026A
High-performance floating-point DSP processing chip
Ultra-low background noise pre-amplifier circuit, low distortion analog circuit, output high-quality sound
Support 4/8/12/16 channel balanced input, with 48V phantom power supply soft-switching, support microphone, line audio signal access
Support 8/16 balanced audio output, support connecting power amplifier, recording device and other devices
Support 4-channel Dante network audio input and output(GX-DSP1025, GX-DSP1026,GX- DSP1025A,GX-DSP1026A)
All input channels are with gain control, noise gate, automatic feedback suppressor, high and low pass filters, parametric equalizer(8 segments), compressor, delay timer and input marshalling
controller
All the output channels are with high and low pass filter, parameter equalizer (8 segments), compressor, delay timer and output marshalling controller
Support matrix mixing, realize free mixing output of any input channel
Dynamic range: 118dB, ADC, DAC
Configure 8 custom function GPIO interfaces
Support USB playback and recording function, can identify Chinese songs
Built-in signal generator: sine wave signal, pink noise, white noise
Front panel with input and output volume status indicators, and error indicators
The panel carries with LCD display monitor, helps display the system status directly
Support RS-232 and TCP/IP protocol, the third-part calling-control could be achievable
Enables to output camera tracking code, be conducive to realize camera linkage function through the third-part calling-control
Support 32 sets of scene preset function, which can be called through RS-232, TCP/IP protocol
Provide simple and easy-to-use control software, support WINDOWS, Android, IOS, the software supports each channel sound control, level indication, preset call, device information query and
other functions
Optional support AEC echo cancellation function
Optional dual-machine data synchronization hot backup function
It can be controlled through Ethernet connection, with intuitive operation interface and simple and efficient setting
We can offer sorts of digital sound processor for sale, and the price of audio processor is reasonable, if you have needs to buy digital sound processor, digital system processor, please
contact us.
As a wireless conference room sound system manufacturer, we can offer sorts of conference system for sale, anything you need, please leave us a message.
