H07V-K H07V-R H07V-U Cable

H07v r cable, h07v-k cable, and h07v u cable are PVC electrical wiring, made of bare copper conductor and PVC insulation material, that conforms to European harmonized standards. The h07v cable is used for building, internal wiring of electrical switchboards, power distribution cabinets, and telecommunications equipment, that can be used for equipment exported to Europe, and that is also recommended as a replacement wire for European-made MRO.

Specifications of H07VK H07V-R H07V-U

NOMINAL CROSS SECTION CONDUCTOR CONSTRUCTION INSULATION THICKNESS OVERALL DIAMETER APPROX. NET WEIGHT MAX. CONDUCTOR RESISTANCE AT 20℃

mm2 No. Diameter mm mm kg/km Ω/km

1 X 1.5 1 1.38 0.7 2.78 19.7 12.1

1 X2.5 1 1.78 0.8 3.38 31.2 7.41

1 X4.0 1 2.25 0.8 3.85 46.1 4.61

1 X6.0 1 2.76 0.8 4.36 65.7 3.08

1 X10 1 3.55 1 5.55 108 1.83.
