LCD Monitor Screen SAD2150KH
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Frameless Housing.
Screen definition: 1920*1080.
Support 1080P video solution.
Full view angle.
Build with HDMI input.
With CE FCC ROHS certification.
LCD Monitor Screen Features
21.5'' Open Frame HD Video Screen
1. 21.5inch HD LCD Screen
2.1920x1080P IPS LCD Panel
3. Open Frame LCD Screens with mounting ears on side edges that can be integrated into a POS Display/POP Display/POSM Display for digital advertising
4. Widely used at point of sales places such as a floor display, gondola display, endcap display, etc.
21.5'' Open Frame HD Video Screen
1. Built-in Speakers for audio output, attracts customers with interactive video and music, increase the interaction between product information to customers in an more effective way.
2. With VESA holes on the back shell, can be used together with standard vesa bracket to mount it on wall or store shelfs. Standard vesa brackets is supported for easily installation.
21.5'' Open Frame HD Video Screen
21.5inch IPS LCD panel with 178° Wide View Full Angle, video and images can be seen from different view angles. Can be placed at any places of the stores.
1920x1080P HD LCD Screen for clear message displayed.
21.5'' Open Frame HD Video Screen
Optional function:
1.Motion sensor (auto power on / off with or without detecting moving body). The video can be activated when the motion sensor detecting a customer passby, easily capture the customer’s attention.
And it can also save energy and power in a standby condition without detecting moving body.
2. Push button (to press the button for playing the files in designated). Suitable for a digital POS Display to display multiple products in a store, customers can press each button to play a
product video and get the information accordingly.
21.5'' Open Frame HD Video Screen
Easily upload contents via USB & SD card.
Auto copy contents from USB to SD Card after power on to update contents.
Auto loop videos after power on.
With HDMI input, can connect a external media player.
21.5'' Open Frame HD Video Screen
Open frame design with "ears" on two sides which makes it more easy to integrate into POP displays. Can be used for different POS displays, like a countertop display, endcap display, gondola
header display.
LCD Monitor Screen Tech Spec
Model SAD2150KH Shell color Standard: black
Open Frame or Enclosed Open Frame LCD Panel 21.5inch
Resolution 1920*1080 Display Ratio 16:9
Brightness 220cd/m2 Contrast 1000:1
Colour 16.7M Visible Angle 178/178
Response Time 8ms Life Time(hrs) 20000 H
Visible Area 476.06x267.79mm(HxV) Outline dimension 548.04*298.55*33.6mm
CPU TSUMV59XU GPU /
Memory / ROM NAND flash /
Decoded Resolution Support 1080P RTC Real-time Clock Support
Switch Time Setting Support System Update U flash disk update
OS Mstar TV Nos External Interface DC IN/DC-SW/Earphone*4/HDMI in/SD/USB
Touch Panel / Camera /
Ethernet Support / Speaker /
External Port Support SD/U flash disk Input AC 100-240V
Output DC 12V/2A Power consumption(Watt) ≤17W
Standby(Watt) ≤1W Material ABS material injection process
Installation 75*75mm VESA Wall Mount Image Format JPEG/BMP/GIF/PNG
Audio Format MP3, WMA, WAV, EAAC+, MP2, dec, Vorbis(Ogg), AC3, FLAC (lossless audio codec), APE, BSAC; Built-in two stereo speakers, with the function of audio output (support external audio
equipment) Video Format MPEG1, MPEG2, H.264 MP4, AVI, MOV, 3GP, RMVP/MKV ETC...
Control Method Remote control Default Language English
Menu Language Support Chinese, English Storage Temperature -20℃~60℃
Working Temperature -20℃~55℃ Storage Humidity 10%-75%
Working Humidity 20%-80%RH Product Weight(N.W. ) 2.6kg
Plug Types US, EU, AU, UK Optional Package Size A single package: 632*72*430mm Bulk packages: 629*196*426mm
Packaging 3pcs/Package Package Weight: 11kg (Reference Only) Accessories User Guide, Instruction Book, Warranty, Desiccant
Optional 1. Motion Sensor 2. Push Button Notes /
We provide liquid crystal display, large format lcd display, big screen for advertising, 22 tft monitor, advertising touch screen, etc. For advertising display screen price or more information,
please feel free to contact us!
