Office Container

Container Office Cabin for Sale

The office container china adopts the current international popular container activity room design concept and manufacturing process with the characteristics of standardization, safe and stable structure, and economic flexibility. The construction cheap office containers can be used in a single container or multiple containers front and rear the combination of up and down (can be built 2-3 layers). The containerized office unit high thermal insulation can create a good office and living environment for field workers. Ideal for construction site offices and residences, factory buildings, field workplaces, roof additional facilities, and other fields. The containerized office unit can be transported as a whole or compressed and packed. The roof, ground, and circuit system are completely prefabricated in the factory, so that the on-site installation is convenient and fast, and the time interval from building to use is shortened.

Office containers have strong adaptability to the environment and are easy to install on site. Container office construction rooms can be widely used as temporary offices, accommodation, integral kitchens, bathrooms, and other purposes for middle and high-grade requirements. According to the actual application, office containers should be equipped with an awning and other decorative accessories. At the project site, the construction time is very short, and transportation to the site can be used. The roof adopts a structural waterproof design to enhance the air tightness and water tightness of the house. Now this kind of office converted containers combines the modern residential architecture concept and is creating a new idea. The container construction office appearance has strong plasticity, can create through the design can show a variety of fashion appearance, delicate and beautiful.

Product Parameters of Cheap Container Office

Size 5950mm(L)*2250mm (W)*2690 mm(H)(external size) 5700mm(L)*2020mm(W)*2390mm(H)(internal size)Or 6050mm(L)*2438mm (W)*2590 mm(H)(external size) 5875mm(L)*2255mm(W)*2325mm(H)(internal size)

Foundation Simple concrete foundation or solid floor slab required

Base Profile steel; Plywood/fiber cement panels+ vinyl/PVC surface flooring.

Steel frame Frame structure: cold formed profile steel, 4mm thickness; Corrosion Protection: Polishing, derusting, sand blasting; Finishing coat: alkyd honed painting； Connected by bolts or screws.

Wall and roof boards Sandwich panels, GI sheet, decoration panels, panels thickness will be 50mm, 75mm, or 100mm PU, EPS, Rockwool or others.

Roof Sandwich panels, GI sheet, asphalt shingle. Panels thickness will be 50mm, 75mm, or 100mm PU, EPS, Rockwool or others.

Outside doors Steel security doors or aluminium doors; The dimensions of doors are 800 X 1950 mm.

Interior doors Wood, aluminum or sandwich panels doors.

Windows Main material is PVC double glass sliding, aluminium, gypsum windows and etc;The window dimensions are 900/1100mm and they may vary upon request.

Exterior decoration PVC ex-hanging panels, metal carved boards or MDF decorative boards and etc.

Electricity The electrical installation is hidden, laid in plaster depth. The cables are HES brand, for the fuses Siemens automates are used. For the sockets cables of 2 X 2.5, lighting 2 X 1.5 are used. The switches and sockets are VIKO brand. In each room, there is one switch and two sockets. Split air conditioning installation will be made at the container.

Sanitary The installations are made plaster depth. Clean water piping are FIRAT brand. The tea furnace is chrome steel kitchen sink. Wash basins and lavatory bowls are DOGVIT brand.

Technical parameters

Standard roof load 0.5KN/m2(can reinforce the structure as required)

wind speed Wind speed designing 210km/h (Chinese standard)

seismic resistance magnitudes 8

Temperature suitable temperature.-50°C~+50°C

Fireproof Grade 3

component long beam 3mm galvanized steel material

Weight 1950kgs

short beam 2.5mm galvanized steel sheet

column on the corner 3mm galvanized steel raw material

secondary beam Z-shaped galvanized steel

Floor panel 18mm plywood panel+12mm laminated floor or 20mm cement-fiber +2mm vinyl flooring

Forklift Two forklift on the base to move from one site to another

External power If possible, we will add one or two external power holes on the roof panel.

Item Material and Specification Size

Dimensions External （L*W*H） 5950mm*3000mm*2800mm Standard

Internal（L*W*H） 5800mm*2800mm*2500mm Standard

Roof structure roof beam ss400-hdg hot dip galvanized profiled parts 5630mm*160*2.3mm

roof rail ss401-hdg hot dip galvanized profiled parts 2680mm*160*2.3mm

roof square tube 50*50*1.8 hot dip galvanized

roof corner 45steel punching tee corner 5mm

roof frame square pipe 40*80*1.2 galvanized

roof frame square pipe 40*60*1.0 galvanized

roof tile 980type contianer special tile 0.45mm

ceiling tile 981type contianer special tile 0.25mm

pressure plate slot 1.2mm galvanized bending

Thermal insulartion material glass wool

Base structure base beam ss400-hdg hot dip galvanized 5630mm*160*2.3mm

base rail ss400-hdg hot dip galvanized 2680mm*160*2.3mm

base corner 45# steel stamping tee corner 4.7mm

base purlin Hot dip galvanized square pipe 1.2mm 40*80*2990

base purlin Hot dip galvanized square pipe 1.2mm 80*80*2990

floor grade A fireproof glass magnesiu board 16mm

Corner column corner column 2.3mm formed section 2480mm*160mm

Painting Plastic spraying + paint baking outdoor plastic powder according to customer color requirements

Connector bracket connecting screw M12*30 strength grade 8.8

frame screw M12*25 galvanized carrage screw

Wind resistant connector of frame body M20

chassic screw long rod galvanized screw M10*100 M10*60

wall panel wallboard doubl-sided rock wool sandwich board steel plate thickness:0.3mm

door and window door plastic-sprayed steel handle with frame

window aliminium alloy security window Single glass aluminum profile window

decorative strip roof corner line 3*3 aluminium alloy

coloumn corner line plastic spraying inner arc aluminum profile width:75mm

optional material: high-grrade decoration material Item Material Remarks

PVC inner corner wall skirt PVC

Flat iron sheet concealed ceiling 0.326 color steel

PVC engineering vinyl roll sheet Refractory plastic many colors is available

High grade hollow glass windows plastic steel Hollow tempered glass

glass curtain aluminum alloy customization

electric equipment Item Brand

The electric box famous brand

Double row leak protector

LED energy-saving lamp tube

An open

Air conditioning socket 16A

USB socket * 4

Galvanized JDG pipe + connector

Single conductor 2.5Square MM, National Standard

Single conductor 2.5 Square MM National Standard

Single conductor 1.5Square MM National Standard

Memo Note: Container toilets are made by aluminum-plastic board floor, stainless steel sink drainage system, all wood-plastic board baffle holes. Exhaust fans, blinds, etc. Shower container aluminum plastic board floor, PVC pipe shower head.

Zhongtai House is a professional prefabricated structural steel frame construction manufacturer, the flat pack container house is our main product, and we can provide a daily production capacity of 200 sets, fully meeting your high-end, middle, and low-end product needs. Our house type includes container house (Flat pack container, Detachable container, Folding container), Prefab house, H beam Steel structure, and cold-formed light steel structure villa. With the modern facility located in the Handan plant, Zhongtai has the capability to manufacture 6,000 Units of container houses and 70000 sqm （ building area ）prefab houses per month.
