Wet Processing Equipment – wet etching machine
Product Quick Detail
- Place Of Origin
- China (Mainland)
- Minimum Order
- 1
- FOB Price
- USD $2,900.00 / Piece
- Packaging
- 4-8box
- Delivery
- 60 Days
Specifications
Wet Processing Equipment for All Chemical Etching Purposes
Wet Processing Equipment – wet etching machine
The etching machine is used to spray chemical solution to a copper-clad laminator, aluminum substrate, or stainless steel plate, the exposed copper, aluminum, and stainless steel are etched away, retaining the pattern or circuit covered by the corrosion-proof film, so as to achieve the purpose of making pattern or circuit.
The etching machine is divided into an acid etching machine, an alkaline etching machine, and a hydrofluoric acid glass etching machine (the three kinds of etching machines can be provided by our company).
Metals that can be processed by wet etching machine
- Wet Etching Invar
- Wet Etching Germanium
- Wet Etching Gallium Nitride (GaN)
- Wet Etching Indium
- Wet Etching Cobalt
- Wet Etching Tungsten
- Wet Etching Stainless Steel
- Wet Etching Aluminum
- Wet Etching Kovar
- Wet Etching Copper
- Wet Etching Steel
- Wet Etching Nickel
- Wet Etching Platinum
- Wet Etching Silver
- Wet Etching Rhodium
- Wet Etching Hafnium
- Wet Etching Vanadium
- Wet Etching Zirconium
- Wet Etching Titanium
- Wet Etching Niobium
- Wet Etching Tantalum
- Wet Etching Molybdenum
- Wet Etching Brass
- Wet Etching Rhenium
Wet Processing Equipment
The acid etching machine is mostly used for etching the inner layer of the circuit board, and the production of small batches of various types of sample boards. Acid copper chloride is generally used (copper chloride is added with hydrochloric acid), which is characterized by easy control, small side corrosion, a large amount of dissolved copper, easy regeneration and recovery, and the etching solution can achieve high-quality etching under stable conditions.
The alkaline etching machine is used for the outer layer of circuit boards, large-scale double-sided board production, and the production of aluminum substrates. Its alkaline etching process has the advantages of cost-saving and easy control.
Wet Chemical Etching Machine
Customize your Equipment
- Check out our Wet Processing Equipment.
- Select the product you are interested in, to find all your possible options.
- Then contact your sales rep to get moving on your new piece of equipment.
- If no products catch your eye please contact us
Our metal etching equipment processing workshop
Features that can be added to a wet etching machine:
- Acid Controller – Popular for cupric chloride etchant
- Drying – Ensures products come out of the line dry.
- Inline Filtration – Results in fewer clogged nozzles and particles in solution.
- Ion Exchange – Saves water in rinse stations.
- pH Controller – Popular option for Alkaline etching. Standard on developing and resisting stripping lines.
- Ventilation Demister – Aids in condensation and recovery of evaporated process chemistry.
- Thin Material Transport – Transport very thin and flexible materials without the use of leaders.
- Drip Pan – Catches chemistry drops or spills
- Chiller Cooling System – Increased cooling capabilities.
- ORP Controller – Popular option for Cupric and Ferric etchers. Comes with a regeneration system.
- Specific Gravity Controller (IX) with Visual Baume – Prevents etchant Baume from getting too low or high.
- Recipe-Driven Operation – Eliminates product variation due to improper machine set-up.
- Data Collection and Archiving – Gives real-time and historical feedback analysis.
Popular Wet Processing Combination Equipment
(DES) Develop – Etch – Strip Line
PCB Etching machine
DES noun explanation
(D) Developing
In photofabrication, developing is the post-exposure process.
Dissolve and remove the photoresist other than those required and form a pattern image of the photoresist.
There is a “soaking method” of immersion in the developer and a “spray method” of spraying, and there is a common use of spray methods in terms of supply efficiency of the developer.
Immediately after the development, a set of heating treatments called post-baking are carried out.
The post-baking box hardens the photoresist, which results in resistance to etching fluid in the next process and improves adherence to substrates.
(E) Etching
Etching is a post-developing process.
While continuously transporting using etchants suitable for metal materials (products), a large amount of etching is performed uniformly by the spray method.
As the management of the etchant is important, an etchant autoanalyzer is installed as a supplementary facility, and various chemicals are automatically supplied based on the feedback of each component analysis to maintain a constant etching rate.
(S) Stripping
Stripping is the post-etching process.
After etching, dissolve the unnecessary photoresist film.
Depending on the type of photo registry, sodium hydroxide heated around 40 to 80℃ or 100℃ is commonly used.
In the case of special resist, mixed solvents such as xylene, alcohols, and ketones may be used.
If the product cannot be stripped by immersion, physical force such as a brush or spray is applied to the product. Immediately after stripping, De-ionized water cleaning, drying, and rust prevention are performed as a set.
DES Line’s Advantages
By installing 3 processes on one device…
- the unit’s area becomes smaller.
- Since there is only one inlet (LD) and outlet (ULD), it can be operated by a minimum number of people.
- It’s cheaper than purchasing three separate machine
DES Line’s disadvantages
By installing 3 processes on one device…
- The tact time of the device is rate-determining in the slowest process.
- When a product defect occurs, it is difficult to determine which process is the cause.
- It is not suitable for various kinds of products whose processing conditions change significantly.
- It is not suitable for research and development purposes that assess and select types of photoresist or film thickness.
(SES) Strip – Etch – Strip Line (outer layers)
The Dragon Etching SES lines
