4CH DWDM Mux Demux

DWDM Mux Demux is usually used for long-haul transmission where wavelengths are packed tightly together over the C-band, up to 48 wavelengths in 100GHz grid(0.8nm) and 96 wavelengths in 50GHz grid(0.4nm). Its protocol is transparent and suits applications including 10/1G Ethernet, SDH/SONET, 16/8/4/2/1G Fibre Channel, FTTX, and CATV.

Our DWDM Mux Demux are modular, saleable, and are perfectly suited to transport PDH, SDH / SONET, ETHERNET services over WDM, CWDM, and DWDM in optical metro edge and access networks.

4CH multiplexer Features

Low Optical Insertion Loss

Mux/Demux Four/Eight wavelengths

SC connectors for interfacing

Reliable passive WDM optical technology

Scales easily for ring networks

Low-profile modular design

Fits in 1RU 19" rack mount chassis

Compliance with ROHS

4CH DWDM Mux Demux Specification

Parameter Unit MUX/DEMUX

Channel Number CH 4

Operating Wavelength nm 1525~1565 Optional

Center Wavelength@λc nm C Band, ITU Grid

Channel Spacing nm 0.8nm(100GHz)

Channel Insertion Loss dB ≤1.5

Pass-band Bandwidth nm ITU±0.11

Channel Ripple dB ≤0.5

Adjacent Channel Isolation dB ≥30

Non-Adjacent Channel Isolation dB ≥35

Return Loss dB ≥50

Directivity dB ≥50

PDL dB ≤0.15

PMD ps ≤0.1

Power Handling mW ≤500

Operating Temperature °C -10~+70

Storage Temperature °C -40 ~+85

Fiber Type - Corning SMF-28e Ultra

Package Size mm 100x80x10
