Hall Sensors

Hall Sensors

Hall sensor is suitable for uninterruptible power supply (UPS), switching power supply (SMPS), welding machine, medical equipment, mobile communication equipment and other power supplies, elevators, forklifts, air conditioning and ventilation equipment, solar energy, wind power generation, process control, battery monitoring, battery management , converter, roadside applications and other system current signal acquisition and feedback control. Small size, long life, easy installation, fast response time, wide current measurement range, high accuracy, strong overload capacity, good linearity, and strong anti-interference ability.

Technical Parameters of Hall Sensors

Specification Input current Rated output measuring aperture(mm) Power supply

AHKC-EKA 0~(20-500)A 5V/4V φ20 ±15V

AHKC-EKAA DC 0~(50-500)A 4-20mA φ20 12V/24V

AHKC-EKDA AC 0~(50-500)A 4-20mA φ20 12V/24V

AHKC-EKB 0~(200-1000)A 5V/4V φ40 ±15V

AHKC-EKBA DC 0~(200-1000)A 4-20mA φ40 12V/24V

AHKC-EKBDA AC 0~(200-1000)A 4-20mA φ40 12V/24V

AHKC-EKC 0~(500-1500)A 5V/4V φ55 ±15V

AHKC-EKCA DC 0~(500-1500)A 4-20mA φ55 12V/24V

AHKC-EKCDA AC 0~(500-1500)A 4-20mA φ55 12V/24V

AHKC-K 0~(400-2000)A 5V/4V 64x16 ±15V

AHKC-KAA DC 0~(400-2000)A 4-20mA 64x16 12V/24V

AHKC-KDA AC 0~(400-2000)A 4-20mA 64x16 12V/24V

AHKC-H 0~(500-3000)A 5V/4V 82x32 ±15V

AHKC-KA 0~(500-5000)A 5V/4V 104x36 ±15V

AHKC-LTA 100A-300A 50mA/100mA φ20 ±15V

As one of hall effect sensor manufacturers, we can provide kinds of hall effect ct sensors for sale, if you are interested, please contact us.
