LST800

Place Of Origin
United States
Minimum Order
1
Packaging
N/A
Delivery
N/A

Optical Specifications


Aperture Diameter 16 mm
Typical Beam Diameter 5 – 14 mm
Maximum Optical Power Handling up to 300 W with Chiller Plate
Optics Options Aluminum, Gold, Dielectric
Dielectric Optics Suffix 1064 nm (-1), 532 nm (-2),
355 nm (-3), 266 nm (-4)
Metal Optics Suffix CO2 (-C2), IR (-IR), STD (-AL)
Laser Induced Damage Threshold 15 J/cm2at 10 ns (Dielectric Optics)

Performance Specifications


Open Delay Time 10 ms
Open Rise Time 40 ms
Total Open Time 50 ms
Close Delay Time 10 ms
Close Fall Time 40 ms
Close Total Time 50 ms
Minimum FWHM Exposure Capability 100 ms
Maximum Shutter Repetition Rate 3 Hz

Thermal Specifications


Thermal Power Dissipation Holding Open 6 W
Thermal Power Dissipation, Repetitive Cycling 15 W @ 3 Hz
Mounting Surface for Thermal Sinking Datum A

Custom Options


Optics Dielectric, Gold, or Overcoated Aluminum
Wire Length, Cable Type Any 6-C cable length
Connector Any 6-Pin Connector, MTA Std.
Identification Engraving, Labels

Electrical Specifications


Power Supply 24 VDC, 3 AMP RATING
Optimum Electrical Drive Circuit
CX4000B
Boost Open = 24 V 35 ms
Boost Ramp-Up = 15 ms
Hold Open = 7 V
Delay = 16 ms
Brake = 24 V for 10 ms
Shutter Winding Resistance 8 ohms Nominal
Nominal Winding Inductance 25 mH
Position Sensors Micro-switch PN 311SM706-T
Cable Type, Length, Termination Six wires, 22 g, 6 ft., flying leads or MTA-100

Wire Pin # - Color


1 – White Power Winding (+)
2 – Black Power Winding (-)
3 – 4 Red/Orange Pair Open Switch,
Reads Continuity When Shutter Open
5 – 6 Blue / Green Pair Closed Switch,
Reads Continuity When Shutter Closed

Attributes


Dimensions 6 in. x 1 in. x 4 in.
Weight ~1.5 lb.
Classification Safety/Pulse Gating
Gravity Considerations Mounting Orientation will affect amount of power used to open.
Not designed for upside-down mounting.
Specifications Date Oct. 5, 2023
