Features
|
System Security
|
Supports three-level account, password, user authority management
|
|
P2P
|
No need to preset camera, Offer free factory P2P(MEYE-000xxx-xxxxx), Plug&play, Support QR code scanning to view
|
|
Cell Phone View
|
Support Iphone and andriod smart view via QR code scanning.
|
|
PC Client
|
PC client "DeviceViewer". Support1,4,9,16,25,36, 64,128-channel , no user limited , centralized monitor, record and playback
|
|
Lens
|
Lens Type
|
Glass Lens Standard : 3.6 mm
|
|
Video
|
Image Compression
|
MJPEG
|
|
Image Frame Rate
|
25fps(50Hz),30fps(60Hz)
|
|
Resolution
|
720P, 640 x 480(VGA), 320 x 240(QVGA)
|
|
Flip Mirror Images
|
Vertical / Horizontal
|
|
Light Frequency
|
50Hz, 60Hz or Outdoor
|
|
Video Parameters
|
Brightness, Contrast
|
|
Night Visibility
|
9 Φ5 IR LEDs, Night visibility up to 10 meters
|
|
Filter Switch
|
Built-in IR Cut,With self-check function,Double optical fliter automatic switch, no color deviation indoor or outdoor.
|
|
Audio
|
Input / Output
|
Built-in Microphone/Built-in Speaker
|
|
Audio Compression
|
ADPCM
|
|
Audio Gain
|
AGC
|
|
Audio Interface
|
Audio Out
|
|
Pan/Tilt
|
Rotation Angle
|
Pan:355°, Tilt: 120° , 10 Level PT Speed Optional,
|
|
Preset
|
Support 16 Preset Positions
|
|
Network
|
Ethernet
|
One 10/100Mbps RJ-45
|
|
Supported Protocol
|
HTTP,FTP,TCP/IP,UDP,SMTP,DHCP,PPPoE,DDNS,UPnP etc.
|
|
IP Mode
|
Dynamic IP address, static IP address, PPPOE
|
|
Online Visitor
|
Support 4 visitors at the same time
|
|
Wireless
|
Wireless Standard
|
IEEE 802.11b/g/n
|
|
Wireless Security
|
WEP, WPA, WPA2 Encryption
|
|
Others
|
Product Type
|
Cartoon Robot/ Indoor use
|
|
Power
|
DC5V 2A
|
|
Working Temperature
|
-10~50 °C
|
|
Working Humidity
|
95% RH
|
|
Size
|
Item size: 106mm x 100mm x 136mm (LxWxH)
|
|
Packaging size: 182mm x 110mm x 149mm (LxWxH)
|
|
Weight
|
N.W.: 350g G.W.: 600g(Note:Actual Weight Final)
|
|
Accessories
|
Adaptor, CD (Software,User Mmanual), Bracket, Screw
|
|
Alarm
|
Alarm Detection
|
Motion detection ,Motion Detect Sensibility can be adjusted
|
|
Alarm Action
|
Support Email photo, FTP photo etc.
|
|
System
|
Supported OS
|
Microsoft Win98 SE/ME/2000/XP/Vista/Windows7 32Bit / Mac OS.
|
|
Browser
|
IE6.0, IE7.0, IE8.0, FireFox, Google or other standard browser
|
|
Certification
|
CE,FCC,RoHS
|
|
Warranty
|
Limited 2-Year Warranty
|
