Jiangsu Fanqun XF Boiling Dryer

Jiangsu Fanqun XF Boiling Dryer - Jiangsu Fanqun Fluidized Bed Dryer - Jiangsu Fanqun Drying Equipment - High Quality

*About Jiangsu Fanqun XF Boiling Dryer

GENERAL DESCRIPTIONS

Boiling dryer is also called as fluidized - bed. I t consists of air filter, heater, fluidized - bed main machine, feeder, cyclone separator, cloth bag duster, high-pressure centrifuge fan and operation table. Because the properties of raw materials exist difference, when equip the dust removing equipment, it should consider the practical need. It can select cyclone separator and cloth bag duster at the same time or one of them. In general speaking, it needs to select cyclone separator only for raw material that is large in specific gravity and cloth bag duster for powder and small granule raw materials that is light in specific gravity. Meanwhile there is air feeding device and belt conveyor for selection.

Separated granule solid raw material is fed into fluidized-bed drier through feeder. Fresh air through filtering and heating is sent to the bottom of fluidized-bed by fan and contacts with solid raw material on distributing plate. In this way the fluidized state is formed and the heat exchange between air and solid is carried out. The dried raw material is discharged from outlet and wasted gas is exhausted from the top of fluidized-bed where catches solid powder through cyclone separator, cloth bag duster.Steam, electricity or hot air furnace can be used (it can be supplied as request).

It is suitable for drying separated granule such as, raw material of pharmaceutical industry, tablet, tablet of drink of Chinese traditional medicines; plastic resin, citric acid, other powder and granule of chemical industry, powder of drink, corn embryo feed of foodstuff industry and so on. The Max diameter of raw material to be dried will 6 mm and the best diameter will be 0.5~3 mm.

Advantages of the Dryer:

Automatic production can be realized. The dryer has a continuous drying. It features high drying speed and low drying temperature. In conformity with the requirements of GMP, the dryer can guarantee the quality of products.

*About Jiangsu Fanqun

Jiangsu Fanqun Drying Equipment Factory and Fanqun Chemical Machinery Co., Ltd. is a stock enterprise created by the founder of China Drying Industry, Fan Bingxi at Changzhou,Jiangsu. The company has a lot of experienced and skilled engineers, banana Plug technicians and technical workers who are engaged in the work of developing, researching, designing and manufacturing drying equipment, e-cigarette & electronic cigarette granulating, mixing and grinding equipments and so on for more than 30 years. The products are well sold all over China and also exported to USA, Japan, Germany, Russia and Southeast Asia Countries and so on. They are welcomed by customers both at home and abroad. Our products enjoy high reputation on the markets. The enterprise is the one that has the largest scale, the most varieties and the best quality of drying machine in China. Sincerely welcome old and new friends both at home and abroad to investigate and guide our enterprise.
