gps vehicle tracking for 900e gps tracker

900E gps tracker

Product information

Specifications

Track on Web or Mobile Phone

Listen-in or Two-way Audio (Use the SMS to set the communication mode)

Internal 2Mb Flash Memory for Logging when the device in the gprs blind area

Support camera

Support LCD (Optional)

Support temperature sensor(Optional)

FEATURES:

Good for tracking, fleet management and security

Track by SMS/GPRS

Band: 900MHz/1800MHz and 850MHz/1900MHz

User can link to the service center GPS tracking website through the Internet to see where is the vehicle on the Google earth and vehicle situation information

Listen-in or Two-way Audio (Use the SMS to set the communication mode)

Internal 2Mb Flash Memory for Logging when the device in the gprs blind area

Support camera. with the monitor camera, the manager can keep abreast of all developments on the vehicle.

Support LCD (Optional),the driver can communion with the manager.

Support temperature sensor(Optional), it can monitor the environment temperature

850mAh Internal Backup Battery

Overspeed alarm cut off oil and engine vibration alarming, door opening alarming, and power-off alarming and unlock alarming

Automatic position report

Remote cut off engine

MainPower off alarm

With LED indicator

Dimensions: 118 x 93 x 6mm

SMS function:

Position Report Function and Tracking Function.

2 outputs can be used to remote cut electricity and oil of the car.

3 inputs can be used to detect unconventionality of your vehicle

SOS Alarm: Set a preset phone number for SOS button, when this button is pressed, device will send one SOS SMS to the SOS preset number.

Over speed alarm: When the vehicle speed higher than the preset value, device will send one over speed alarm SMS to the SOS preset number.

GPRS function:

Positioning function: After the GPS implements satellite positioning, it sends the data such as longitude & latitude, speed and azimuth of the target to the monitoring center. This function can be implemented through Google Earth with the support of

an appropriate software system.

Hijack alarm: In case of danger, push the button hidden in the steering room, and the vehicle-mounted system will send alarm signals to the monitoring center until a response is received from the monitoring center.

Tracking: The monitoring center can track the vehicle which raises the alarm after the vehicle is stolen or robbed.

Remote flameout: In the process of rescuing the hijacked vehicle, the monitoring center can extinguish the vehicle remotely by force as required. The system provides double safety, and device fault will not cause accidental flameout.

Authorized wiretapping: The vehicle can be wiretapped as authorized (a tiny microphone needs to be installed).

Internal flash memory: When the 800E is disconnected to the system (for example, the GPRS signal is weak), the position data will be storing in the flash, and then it will upload again after it reconnect to the system (the GPRS signal is ok).

Support serial cameras: monitor the image information around the terminal.

GPS/GPRS Specification:

SOS Button :Driver can press SOS button for emergency

General :L1 1575.42MHz, C/A code, 20 Parallel Channels

Sensitivity: -143 dBm minimum

Accuracy Position: 10m CEP without S/A

Velocity: 0.1 m/sec without S/A

WAAS Accuracy Position: 5m CEP

Velocity: 0.05m/sec

Acquisition:(1)Cold start: < 60sec average(2)Warm start: < 45sec average(3)Hot start: < 15sec average

Antenna: External GSM and GPS Antenna

Dimensions: 125.0mm*70.0mm*24.0mm

Power Specification:

Backup Battery: Built-in Rechargeable Battery

Power Voltage: DC 9V-40V

Environmental Specification:

Operation Temperature: -20ºC to +70ºC

Storage Temperature:-30ºC to +85ºC

Operating Humidity: 5% to 95%
