22T PLC Zinc injection machine
Product Quick Detail
- Packaging
- wooden case
- Delivery
- 75 Days
Specifications
| Tonnage:22T | Die locking force:220KN | Tie-bars dia.:40MM |
| Die stroke: 130MM | Tie bars space:232*278MM | Mold thickness:150-220MM |
| Max.injection force: 21KN | Ejection force:13KN | Flow rate of oil pump:31L/min |
| Working oil pressure:6-7Mpa | Output of pump motor:5.5/6Kw/P | Melting pot capacity(Zn.):120KG |
| Accumulator capacity:10L | Oil tank capacity:200L | Input of furnace heating:9KW |
| Machine weight : 2.0T | Machine size: 3000*980*1700MM | (PLC control system can be used.) |
KYLT 22T PLC Zinc
injection machine,also named, 22T zinc(Zn.) hot chamber casting machine, zinc metal injection machine,or metal casting machine, zipper casting
/injection machine.
Other we have 12T,18T,20T,30T hot chamber die casting machines for our client to choose.Those machines can be used to cast, zinc(Zn. or Zamark), lead(Pb.), Tin alloy etc
low melting point materials.
Main used to cast: zinc
auto parts, zinc zipper head and puller,zinc spoon, coin, lable, logo, jewelry, battery lead(Pb.) bushing and terminal etc.
More information,please
email: kylt@cnkylt.com OR stonechenpeng@aliyun.com
- Country: Hong Kong
- Business Type:
- Market:
- Founded Year:
- Address:gaunhou village,wujin,changzhou
- Contact:judy chang
