pv module uv test chamber
Product Quick Detail
- Effective Radiation Area 600×1270mm
- Surface temperature of module 60℃
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Model | Effective Irradiation Area（D*W）mm |
| LRHS-NF | 600×1270 |
| LRHS-NFX | 1820×1000 |
|
|
|
| Lenpure Photovoltaic Module UV Test Chamber | |
| 1 Technical parameters | |
| 1.1. Effective radiation area | 600×1270mm |
| 1.2. Surface temperature of module | 60℃ |
| 1.3. Temperature volatility | ±0.5℃ |
| 1.4. Temperature resolution | 0.1℃ |
| 1.5. Space between lamps | 70mm |
| 1.6. Illumination | Uniformity of module’s test surface: ±15% |
| 1.7. Air flow rate | 0.5～1.0m/S |
| 1.8. Light source | 3 UV-A lamps and 3 UV-B lamps of well-known brand imported from America, i.e., 6 lamps shall be used at the same time |
| 1.9. UVB-313 Wave Length | 280～320nm |
| 1.10. UVA-340 Wave Length | 313～340nm |
| 1.11. Accessories | 1 sample shelf, 6 imported lamps (NF), 24 imported lamps (NFX) and 1 hand-held irradiance meter |
| 1.12. Parallel distance between test specimen and lamp surface | Reach wavelength requirements of sample test finally (the height of test specimen platform is adjustable) |
| 1.13. Total Power | 4KW |
| 1.14. Power Supply Requirements | AC380V±10% 50±0.5Hz (three phases five wires) |
