Electric Winch 3000LBS

ATV/UTV Electric Winch Features: chinacoal05

1.Brake Assembly
Mechanical brake design , makes vehicle safety on the steep

2. Waterproof Design
Level six water-proof design expands the use of situation and long life time.

3. Low -temperature Grease
The gear box using low-temperature grease (-40 ) so that the gear can still work freely in extreme cold weather.

4. Big-power and endurable motor.
With high-performance magnet ,silver and copper commutator , high-density carbon brush , endurable 130 oil painting on wire.

5. High-quality synthetic rope instead of wire rope , make the winch light weight

Our company established in 1982,is specialized in electric winch, ATV/UTV electric winch, 4WD winch/off road winch,boat trailer

winch,car winch,track winch,various kinds of electric winches for your choise,welcome contact us at any time.

s*�re��� @� lt:0.7500pt solid rgb(204,204,204); border-top:0.7500pt solid rgb(204,204,204); mso-border-top-alt:0.7500pt solid rgb(204,204,204); border-bottom:0.7500pt solid rgb(204,204,204); mso-border-bottom-alt:0.7500pt solid rgb(204,204,204); background:rgb(255,255,255); " >

2000lb(907kg)

Motor

0.7KW/0.9hp(12V) permanent magnet

Gear train

1 Stage Planetary

Gear ratio

153:1

Cable

5/32" x 50'(4.0mmx15.2m)

Drum size

1.24” x 2.88”(31.5 x 73mm)

Dimensions

L x W x H (285 x 105 x 105mm)

Mounting bolt pattern

3.13”(79.5mm)

Weight

G/W:9.0KGS N/W:7.5KGS
