SPECIFICATION :
FRAME
M5 hydroformed tubing, 29" EVO geometry, tapered headtube, PF30 BB, internal Command Post BlackLite routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, bolt-on
cable guides, 120mm travel
REAR SHOCK
Custom FOX Float CTD Evolution w/ AUTOSAG, air spring, lockout, rebound adjust, 197x51mm
FORK
Custom RockShox Reba RC 29, Solo Air spring, tapered alloy steerer, compression and rebound adjust, 120mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise
HANDLEBARS
Specialized XC, mini rise, 6000 butted alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, Others: XL
FRONT BRAKE
Shimano Deore BR-M615, hydraulic disc, Ice Tech pads, S/M: 180mm rotor, Others: 200mm
REAR BRAKE
Shimano Deore BR-M615, hydraulic disc, Ice Tech pads, S/M: 160mm rotor, Others: 180mm
BRAKE LEVERS
Shimano Deore BL-M615, hydraulic, alloy lever
FRONT DERAILLEUR
SRAM X7, 2x10, S3 direct mount
REAR DERAILLEUR
SRAM X9 Type 2, 10-speed, mid cage
SHIFT LEVERS
SRAM X7, 10-speed, w/ MatchMaker clamp
CASSETTE
SRAM PG 1030, 10-speed, 11-36
CHAIN
SRAM PC 1031, 10-speed, w/ PowerLink, nickel finish
CRANKSET
Custom SRAM S-1250, 7050 alloy arms, 10-speed AM double, PF30 spindle, 36/22
BOTTOM BRACKET
SRAM, PF30, OS press-in bearings, sealed cartridge
PEDALS
Resin test ride, w/ toe clips, CEN std.
RIMS
Roval Fattie 29, alloy disc, 29mm inner width, 24/28h
FRONT HUB
Specialized Hi Lo disc, sealed cartridge bearings, 15mm thru-axle, 24h
REAR HUB
Specialized Hi Lo disc, 4 sealed cartridge bearings, 12mm thru-axle, 28h
SPOKES
DT Swiss Industry, stainless
FRONT TIRE
Specialized Butcher Control, 60TPI, 2Bliss Ready, folding bead, dual compound, 29x2.3"
REAR TIRE
Specialized Ground Control, 60 TPI, 2Bliss Ready, folding bead, 29x2.3"
INNER TUBES
Ultralight, presta valve
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized alloy, single bolt, 30.9mm
SEAT BINDER
Specialized 7050 alloy, single bolt, 34.9mm
SPECIFICATION : FRAME FACT 9m carbon, Trail 29 Geometry, FACT IS carbon construction, M5 alloy rear triangle, SWAT Door integration, internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 120mm travel REAR SHOCK FOX Float ...
