Samsung smt parts

Samsung Nozzles

Samsung SM-320, CP-45NEO
Part Number Description
J9055133B Ø0.5 / Ø0.25 (CN030)
J9055134B Ø0.7 / Ø0.38 (CN040)
J9055135B Ø1.2 / Ø0.65 (CN065)
J9055138B Ø2.2 / Ø1.4 (CN140)
J9055139B Ø3.6 / Ø2.2 (CN220)
J9055218A Ø6.2 / Ø4.0 (CN400N)
J9055142B Ø9.0 / Ø7.5 (CN750)
J9055143B Ø12.7 / Ø11 (CN110)
SPECIAL Pad Nozzles
SPECIAL Connector Nozzles

Samsung CP-45, CP-50, CP-60
Part Number Description
TN03 Ø0.5 / Ø0.25 (0603)
J7055246A Ø0.7 / Ø0.38 (TN04)
J7055267A Ø1.2 / Ø0.65 (TN065)
J7055131C Ø2.2 / Ø1.4 (TN14)
J7055132C Ø3.6 / Ø2.2 (TN22)
J7055133C Ø6.2 / Ø4.0 (TN40)
J7055135C Ø9.0 / Ø7.5 (TN75)
J7055137C Ø12.7 / Ø11 (TN110)
Bellows Comp' Ass'y
SPECIAL Pad Nozzles
SPECIAL Connector Nozzles

Samsung CP-40C(V)
Part Number Description
N045 Ø1.0 / Ø0.45
N08 Ø1.4 / Ø0.8
N14 Ø2.2 / Ø1.4
N24 Ø4.0 / Ø2.4
N40 Ø6.2 / Ø4.0
N75 Ø9.0 / Ø7.5
N110 Ø12.7 / Ø11.0
Bellows Comp' Ass'y
Samsung Dispense Nozzles

Samsung DP-20
Part Number Description
DP-20 2D/2S 0.6 / 0.3 P=0.7
DP-20 2D/2S 0.7 / 0.4 P=0.8
DP-20 2D/2S 0.8 / 0.5 P=1.0

Samsung DP-50
Part Number Description
DP-50 2D/2S 0.6 / 0.3 P=0.7
DP-50 2D/2S 0.7 / 0.4 P=0.8
DP-50 2D/2S 0.8 / 0.5 P=1.0
