mucking rock loader

Place Of Origin
China (Mainland)
Packaging
carton box, plastic bags, wooden cases or as your requirement
Delivery
5 Days

Chinacoal07 mucking rock loader,rock loader

mucking rock loader

Product Introduction:

Z17AW rock loader is used to load the rock, ore when the explosive blows up the big rock or ore.

Loading materials: gold, nonferrous metal, black metal, nonmetal, and rock, ore, and etc.

The max. diameter of the medium is 500mm. When the diameter is 250mm,

the loading efficiency is best. It runs on the railway track, so the wheel gauge is 600mm in normal,

when the gauge is 762mm, 900mm, or others, pls tell in advance.

Safety Requirement

1. strictly prohibit other people to operate the machine expect the technicist.

2. Strictly prohibit two people work at each side together.

3. Strictly prohibit check the machine before the electric motor put off.

4. Scope of application: section of the tunnel: width: >=1.8m, Height: >=2.0m

Technical Parameters:

1, bucket volume: 0.17+-0.017M3

2, technique productivity: >=30M3/h

3, unload height: >=1210m

4,unload distance: >=270m

5, max. working height: 1920m

6, gauge: 600mm

7, wheel diameter: 850mm

8, transfer overall dimension: (L*W*H): 2120*1056*1260mm

9, electric motor: speed: 750r/min; working motor power: 10.5kw as your requirement;

take up the bucket power: 10.5kw as your requirements.

10, working speed: about 0.85m/s

11, bucket promoting speed: 0.46-0.71m/s

12, weight: 3500kg
