1. Designed and produced according to the standard of En13157.
2. Made of low alloy steel, safe, reliable and durable.
Products No. | Unit | BLJX04-01 | BLJX04-02 | BLJX04-03 | BLJX04-04 | BLJX04-05 |
Rated load ( KN) | Ton | 0.75 | 1.5 | 3 | 6 | 9 |
Stand height | M | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Test capacity | KN | 11.0 | 22.5 | 37.5 | 75.0 | 112.5 |
Maxi. operation force | N | 140 | 240 | 320 | 340 | 360 |
No. of lifting chains | 1 | 1 | 1 | 2 | 3 | |
Dia. Of lifting chain | MM | 6 | 8 | 10 | 10 | 10 |
Sizes (mm) | A | 155 | 180 | 215 | 215 | 215 |
B | 95 | 105 | 130 | 130 | 130 | |
C | 135 | 155 | 211 | 254 | 330 | |
D | 37 | 45 | 50 | 64 | 85 | |
H | 320 | 380 | 480 | 600 | 700 | |
L | 285 | 370 | 410 | 410 | 410 | |
K | 26 | 45 | 50 | 64 | 85 | |
N.W. | KG | 7.7 | 11.8 | 21 | 32 | 47 |
Package sizes | CM | 35.5×14×16.5 | 46.5×15.5×19 | 51×19×21.5 | 53×22×21.5 | 82×32×21.5 |
Raising weight per meter | KG | 0.8 | 1.4 | --- | 4.4 | 6.6 |
