APEX1325-Stone "heavy duty machining" made in china
Product Quick Detail
- Minimum Order
- 1
- Place Of Origin
- c
- Packaging
- wooden box
- Delivery
- 15 Days
Specifications
Parameter
All of these models can be customized according to customer requirements.
| NO. | Description | Parameter |
| 1 | X,Y,Z working area | 1300*2500*300mm(1500*3000*300mm, 2000*3000*300mm) |
| 2 | Drive and motor | Yako stepper motor/driver |
| 3 | Spindle | 3kw/4.5kw/6kw watercooling spindle |
| 4 | Inverter | Delta frequency inverter |
| 5 | Control system | NCstudio/ Mach3/DSP controller |
| 6 | X, Y, Z Travelling Positioning Accuracy | ±0.05/300mm |
| 7 | X, Y, Z Travelling Repositioning Accuracy | ±0.05mm |
| 8 | Frame | Big thickened Steel Square Tubes, thickness up to 8mm |
| 9 | X, Y structure | Rack and pinion, Hiwin square rails on X, Y axis |
| 10 | Z structure | Taiwan TBI Ballscrew, Hiwin square rails on Z axis |
| 11 | Max Rapid Travel Rate | 30,000mm/min |
| 12 | Max working speed | 18,000mm/min |
| 13 | Working voltage | AC220V/380V, three phase |
| 14 | Command languages | G code |
| 15 | Running Environment Temperature | 0 degree - 45 degree |
| 16 | Software | Type3 English version; Artcam English version |
| 17 | Net weight | 1550KGS; 1750KGS; 2100KGS |
| 18 | Gross weight | 1750KGS; 1950KGS; 2300KGS |
| 19 | Relative Humidity: | 30% - 75% |
| 20 | Guarantee | One year from the date of commission |
| 21 | Optional Accessories |
①Rotary system
②Mist-cooling system |
Application
•This machine is widely used in stone industry, such as natural marble, granite, artificial stone, tombstones,
milepost, ceramic tile, glass and other materials.
•Metal mold industry, such as copper engraving cutting.
Youtube links:
NO.1 jinan apex cnctech china cnc stone machine video
NO.2 china cnc stone "granite router machine"
NO.3 jinan apex cnctech marble engraving machine
NO.4 "heavy duty machining" CNC carving stone machine engraving
