SPECIFICATION :FRAME
New Specialized M4 Premium Aluminum, XC 29er Geometry, fully butted w/ smooth welds, tapered headtube and seat tube, forged post-mount 160mm disc dropouts, replaceable alloy derailleur hanger
SWAT
-
REAR SHOCK
-
FORK
RockShox Reba RL 29, TurnKey damping w/ Push-Loc remote lockout, Solo Air spring, tapered alloy steerer, 32mm alloy stanchions, external rebound adj., S: 80mm travel, Others: 100mm travel
HEADSET
1-1/8" upper and 1-1/2" lower threadless, Campy style, integrated full cartridge bearings
STEM
Specialized 3D forged 6061 alloy, 4-bolt clamp, 6-degree rise, 31.8mm
HANDLEBARS
Specialized mini riser, double-butted 6061 alloy, 700mm wide, 10-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Body Geometry XC Contour, Kraton w/ gel, closed end, 132mm, lock-on
FRONT BRAKE
Shimano Deore BR-505, hydraulic disc, 180mm rotor
REAR BRAKE
Shimano Deore BR-505, hydraulic disc, 160mm rotor
BRAKE LEVERS
Shimano Deore BR-505, hydraulic lever w/ reach adj.
FRONT DERAILLEUR
SRAM X7, 10-speed 2X10, 34.9mm clamp
REAR DERAILLEUR
Shimano Deore XT Shadow Plus, 10-speed, GS cage
SHIFT LEVERS
Shimano Deore, 10-speed Rapidfire Plus, w/ optical display
CASSETTE
SRAM PG 1030, 10-speed, 11-36
CHAIN
KMC X10
CRANKSET
Custom SRAM S-1255, 2pc., 10-speed XC double for 29er
CHAINRINGS
36/22, aluminum
BOTTOM BRACKET
SRAM GXP BB for 2pc., 73mm shell
PEDALS
Alloy, 1pc. body and cage, w/ reflectors, 9/16"
RIMS
Crave SL Disc 29", alloy double-wall, sleeve joint, 26mm, 28h/32h
FRONT HUB
Specialized disc, alloy, Hi Lo flange, RCC ball bearing system, steel axle, QR, 28h
REAR HUB
Specialized disc, alloy, Hi Lo flange, RCC ball bearing system, steel axle, steel cassette body, QR, 32h
SPOKES
Stainless, 14g (2.0mm)
FRONT TIRE
Specialized Ground Control, 29x2.1", aramid bead, 60TPI
REAR TIRE
Specialized Fast Trak Control, 29x2.0", aramid bead, 60TPI
INNER TUBES
Standard presta valve
SADDLE
Specialized Body Geometry Henge, steel rails, 143mm
SEATPOST
Specialized alloy, 2-bolt, micro-adjust, 12.5mm offset, 27.2mm, size-specific 350mm/400mm
SEAT BINDER
Forged alloy, 31.8mm, QR, brass washer
