YN27 rock drill
Product Quick Detail
- Place Of Origin
- China(Mainland)
- Packaging
- one piece per carton
- Delivery
- 5-7 days after payment
Specifications
Weight
27kg
Dimension
746*315*229mm
Diameter of engine piston
Φ58mm
Stroke of engine piston
70mm
Rotating speed of engine
≥2450R/min
Rotating speed of drilling rod
≥250R/min
Oil consumption
≤0.12L/min
Tank capacity
1.65L
Max. drilling depth
6m
Shank size
Hex22x108mm
Ignition system
controllable silicon, contactless system
Mixture ratio of gasoline and lubrication oil
12:1
you can try for drilling to get through more products
