Chassis | Brand | Dongfeng CLW | |
Chassis model | CLW5250GJB3 | ||
Drive model | 6*4 | ||
Tire | 11.00R20 | ||
Brake | Air brake | ||
Engine | Model | YC6M340-33 | |
Horse Power | 340 | ||
Main Parameter | Overrall dimension(MM) | L*W*H | 9170 *2500*3970 |
wheelbase | 3800+1350 | ||
Axles No. | 3 | ||
weight | GVW | 25000 | |
Payload weight | 12500 | ||
Curb weight | 12305 | ||
Approaching/Departure Angle(°) | 32/34 | ||
Front/Rear suspension(mm) | 1245/2505 | ||
Max speed(km/h) | 90 | ||
Gear box | 9 speed | ||
Front/Rear Axle Load | 7/16T | ||
Technical Paratmeters of Mixing Tube | Tube Geometric Volume(M³) | 6/8 | |
Mixing Volume(M³) | 6 | ||
Filling Rate(%) | 68% | ||
Rate of Feeding(M³/min) | ≥3 | ||
Rate of Delivery(M³/min) | ≥2.0 | ||
The Remaining Rate(%) | ≤1.0 | ||
Tube Service Speed(r/min) | 0~12 | ||
Tube Dip(°) | 13~15 | ||
Hydraulic Drive | Hydraulic pump | Import from Italy PMP | |
Hydraulic Motor | |||
Speed reducer |
1.The concrete mixing transport tanks and dump truck chassis with the 2nd horse bolts and dedicated horn securely joined to form a concrete truck. 2.It can rely on the dump truck driven power take power gear pumps, hydraulic. The motor driving the tanker operation. 3.By control ...
