Hastelloy C276 Alloy is a Ni-Cr-Mo alloy containing W and extremely low carbon and Si contents.
Density: 8.89
Corrosion resistance
Hastelloy C276 Alloy can be used in many chemical processes with oxidizing and with reducing media. The high molybdenum and chromium contents render the alloy resistant to chloride ion attack. The tungsten content further increases this resistance. Hastelloy C276 Alloy is one of the few materials that is resistant to moist chlorine gas, hypochlorite and chlorine dioxide solutions. The alloy exhibits excellent resistance to concentrated solutions of oxidizing salts (such as iron (III) chloride and copper chloride).
Hastelloy C276 Alloy finds wide application in the chemical and petrochemical industry, for components in organic processes containing chlorides, and for catalytic systems. This material is especially suitable for use in situations where hot, contaminated mineral acids, solutions and organic acids (such as formic and acetic acid) as well as sea water are encountered.
Chemical composition
Ni | Cr | Fe | C | Mn | Si | Mo | W | Co | V | P | S | |
min(%) | bal. | 14.5 | 4.0 | 15.0 | 3.0 | |||||||
max(%) | 16.5 | 7.0 | 0.01 | 1.0 | 0.08 | 17.0 | 4.5 | 2.5 | 0.35 | 0.04 | 0.03 |
Mechanical properties
Condition | Yield Strength(Mpa) | Tensile Strength(Mpa) | Elongation(%) | Hardness(HB) | |
ASTM Min Value | Solution Annealed | 283 | 690 | 40 | |
Typical Values at RT | Solution Annealed | 402 | 794 | 60 | 195 |
International Specification Comparison chart
Material | Round Bar | Sheet | Pipe | ||
Seamless | Welded | ||||
ASTM |
UNS N10276 |
B574 | B575 | B622 | B619/B626 |
ASME | SB574 | SB575 | SB622 | SB619/SB626 | |
JIS | NW0276 | H4553 | H4551 | H4552 | |
DIN | 2.4819 | 17752 | 17750 | 17751 | 17751 |
