Belt Drive Balancing Machine YYQ-3000A
Mass Range of Workpiece kg:100-3000
Max Diameter of Workpiece mm:2000
Distance between Two Bearing Support mm:150-2600
Rotor Diameter Range mm: 15-300
Belt Position Diameter Range mm:40-900
Balancing Speed min r/mm:180-2500
Drive Power kw:11
Feature
1.Belt driving
2.Horizontal hard bearing dynamic balancing machine
3.Motor and Inverter for speed regulation
4.Industrial computer to process data
5.Colored screen display unbalance value, phase angle, and practical rotation speed
6.Software has two calibration function like usual piece and standard rotor
7.Friendly interface to input,preview,test, save and type data
8.Machine tool can be lengthened on request
9.Overall cast base, better stability
10.Balance test on single side, double side, multi side
11.High accuracy, direct, dependable quality, convenient maintenance
12.Equipped with Variable speed motor to drive which ensures high quality balancing and precision
13.Quick booting ,easy operation. and high efficiency
you can try balancing machine to get through more products
