1, Simple up and down device: the simple up and down device can adjust the horizontal height of anchor cable hole easily. Wear resisting Nylon plate can prevent guide track from wearing when power head operates. 2, reliable power head: cycloidal gear reductor and electric motor forms power head. The power and torque transmit is stable and big. The air packet is the air source inlet of impactor, in the meanwhile it can reduce the impact of power head from drilling rod. 3, Reliable propulsion device: This device adopts hydro-cylinder and chain propulsion with compact structure, big lifting force and good stability.
Technical Parameters
model | HF40 |
bore depth | 10~60m |
bore diameter | 90~180mm |
drilling rod diameter | 76 x 1500mm |
bore dip angle | 0~90 |
power head torque | 2400N-m |
max. lifting force | 25KN |
max. propulsion force | 0~20KN |
electric motor power for power head | 5.5kw or 7.5kw |
electric motor power for hydraulic system | 4kw |
weight | 500kg |
max. component weight | 150kg |
overall dimension | 2800x800x1400mm |
