Item | Parameter |
1、Dimension parameters | |
Appearance dimension (length x width x height) | 5650×2000×2350mm |
Front suspension | 1015mm |
Rear suspension | 1275mm |
Angle of approach | 24° |
Angle of departure | 25° |
Minimum ground clearance | 190mm |
Volume of garbage compartment | 5m3 |
Volume of water tank | 1100L |
2、Quality Parameters | |
Kerb mass | 4600kg |
Unladen weight of front axle | 1800kg |
Unladen weight of rear axle | 2800kg |
Gross weight of front axle | 2100kg |
Gross weight of rear axle | 3700kg |
Max. Gross mass | 5800kg |
3、Performance parameter | |
Sweeping width | 2.5-3.2m |
Operating speed | 3-15km/h |
Maximum speed | 98 km/h |
Maximum grade ability | 30% |
Maximum equivalent diameter of suction | 116mm |
Inclination angle of garbage self-dumping | 60° |
Sweeping efficiency | 96% |
Working temperature | -10°—50° |
Rated passengers | 2 |
Continuous working hours | ≤8h |
Minimum turning radius | 13.6m |
Hydraulic oil tank capacity Hydraulic oil tank capacity | 58L |
Volume of fuel tank Volume of fuel tank | 80L |
Oil consumption during operation(8Km/h) | 6.8L/h |
Oil consumption of driving | 10.6L/100km |
Vehicle-side noise | <80db(A) |
4、Hydraulic system | |
Max. working pressure | 14Mpa |
Hydraulic oil model | HM-46(HM-32) |
5、Electric system | |
Control mode | PLC program control |
System voltage | 12V |
Voltage of work devices | 12V |
Monitoring devices | standard configuration |
6、Cleaning device | |
Distribution mode | Two sweeping plates at middle and sucker in rear, imported hydraulic motor for drive, Two sweeping plates at middle and sucker in rear, imported hydraulic motor for drive, speed of sweeping brush enables stepless speed |
Disk diameter | Φ900mm |
Disk inclination angle regulation | Forerake 4—6°,Extroversion 2—5° Forerake angle: 4~6°, camber angle: 2~5° |
7、Pumping system | |
Diameter of the straw Sucker diameter | Φ200mm |
Ground clearance during working Clearance between bottom side of sucker and ground under working condition | 5-10mm |
Draught fan model Fan model | Dedicated draught fan Dedicated fan |
