Features
1.Used for processing lock-holes and grooves on aluminium windows and doors.
2.Copy-routing processing is available.
3.It can realize horizontal drilling of three holes and vertical copy routing of long holes.
Parameters
Power supply: 380V 50Hz
Motor Power: 1.85KW
Rotary: 2800rpm
Air pressure: 0.5—0.8Mpa
Diameter of milling: Φ5mm
Diameter of drilling bit: Φ12mm
Copy Dimension: 290×90mm
Overall dimension: 1000mm×1100mm×1500mm
Weight: 270Kg
