Technical Specifications:
Parameter | Value | Note |
Wavelength | 808nm+/-10nm | 940nm optional |
Pulse Width | 25ms~950ms | |
Repetition Rate | 1Hz~20Hz | |
Energy Fluence | 0~120J/cm2 | Up to 150J/cm2 optional |
Beam Type | Collimated | Un-collimated optional |
Skin Cooling | TEC + Sapphire | <5℃ |
Laser Window | 10x16mm | |
Laser Cooling Liquid | Purified Water | Tap water allowed |
Water Tank Volume | ~3L | |
Handle Piece Flow Rate | 3.5~4.5L/min | |
LCD Screen | 8’ Touch LCD | 6’~10.4’ optional |
Pedal Switch | Support | |
Environment Temperature | 5~28℃ | |
Environment Moisture | <80% | |
Input VAC | 220VAC / 50-60Hz | 110VAC optional |
Dimension | ~34x34x92cm | Optional |
Weight |
~40KG | Optional |
