AA59326 Stainless steel Acoples Rapidos

Stainless steel camlock coupling

1.key words: stainless steel camlock couplings, quick couplings, cam lock couplings, camlock fittings, quick camlock

coupling, stainless steel 304/316 camlock couplings, hot sale stainless steel camlock coupling, high quality stainless steel

camlock couplings.

2. Stainless steel camlock fittings also used with salt water, water waste and many chemicals & can also be used with

hydraulic oil and coolants.

3. Features: Excellent corrosive resistance;high temperature ability; Long life expectancy;

Wide working temperature.

Working pressure: no more than 250 psi;

Temperature range: -150°F to +500°F (-101°C to +260°C);

4. Material: stainless steel 316, stainless steel 304

Sizes: 1/2\\\" to 8\\\"

Spce: A B C D E F DC DP FC FA

Thread: NPT, BSPP, BSPT

Camlock coupling: Gravity casting/Die casting

Pins, Rings and Safety clip material: Carbon steel plated or stainless steel

Handle material: Brass or stainless steel

Seal: NBR, BUNA, EPDM, VITON

Standard: A-A-59326 (previously called MIL-C-27487) or DIN 2828.

Product Descriotion

Type A B C D E F DC DP FLC FLA

Body Material Stainless steel304/316,

Handle material Brass, stainless steel 304/316

size 1/2\\\"-6\\\"

Seal Buna(NBR),Viton and Teflon

Thread NPT, BSPP, BSPT

Pins, rings and safety clip Carbon steel plated or stainless steel

Standard MIL-C27487 OR A-A-59326 OR DIN 2828.

Working pressure no more than 250 psi;

Temperature range -150°F to +500°F (-101°C to +260°C)

Application oil, petroleum, chemical, water, gas

5.We aslo sell hose couplings ( Camlock, Sotrz, Bauer Guillenmin couplings ), stainless pipe fittings, valves, flanges,

sanitary fittings and valves and so on.

6. Packing :polybag inside, cartons outside; Delivery time:30days on we signed order.

7. Terms of payment: T/T, L/C,30% deposit. Delivery Port: FOB Qingdao.
