11M3 Geometric Capacity LO2 Liquid Oxygen Tank Container

Technical parameters:
Product model JXY5250GDY1-0.8
Loading medium LO2 (Liquid oxygen)
Working pressure(MPa) 0.8
Geometic capacity(M3) 11
Valid capacity(M3) 10.12
Tank material Inner: 06Cr19Ni10/S30408
Outer jacket: Q345R
Curb weight(KG) 13335
Rated load(KG) 11535
Gross weight(KG) 25000
Outer dimension(L*W*H mm) 9330*2500*3105
Insulation method High vacuum multi-layer
Our cryogenic tanks conform to GB150, GB18442 standard and ASME standard, are suitable for liquefied natural gas (LNG), liquid nitrogen(LN2), liquid oxygen(LO2), liquid argon(LAr) etc. cryogenic liquid storage and application. Different volumes of tanks are available, and the maximum allowable working pressure is 0.8MPa and 1.2MPa.

We adopt advanced vacuum acquisition and maintenance technology to guarantee good insulation performance, long vacuum holding time and low maintenance cost.

External pipelines adopt modular design and prefabrication, which can be more compact and concise, and the user can get more reliable system, more convenient installation, maintenance and lower maintenance costs.

It passes CCS attestation and can meet international marine requirements with certificate issued by International Classification Society according to user’ demand.
