Double side automatic screen coating machine

Application scope: The series is suitable for screen printing screen high-precision photographic emulsion coating.

Features:

(1) PLC programmable controller and HMI composition as the operating control system.

(2) Full automatic operation via touch-screen settings, ordinary plate-maker can be easy to produce high-quality precision screen.

(3) Fixing clamps / Unlock clamps set by a foot switch which controls the air pressure, easy to load and unload screen.

(4) Coating speed, coating time and a single, double-sided coating can be freely set.

(5) With pressure regulating function, the coating thickness can be controlled via a set number of application times and applying pressure.

(6) While reaching stop position would automatically slow down to 20mm near the frame, no need to fix screen extra edges.

(7) Use of rail steel with special low vibration, ripple-free coating process.

(8) Operating system with multi languages, multiple coating patterns, and detailed parameter settings.

(9) Special corrosion-resistant treatment aluminum scoop coater, with no clearance with the coating structure, maintain stable emulsion coating.

(10) Servo model is optional.

Parameters:
Model CAD-1000 CAD-1315

Min frame size (OD) 600 X 600mm 600 X 600mm

Coating speed 50 ~ 150mm/sec

Frame fixing Foot switch quick fixed

Air pressure 6kg/cm2

Weight Approx. 380kg Approx. 450kg

Power 220V X 1ph X 450W 220V X 1ph X 600W

Dimension (W X D X H) 1920 X 580 X 1900mm 2120 X 580 X 2300mm

Customized frame size can be made for requirement.

We have normal model automatic coating machine for 600*800mm, 1000*1000mm, 1200*2400mm etc size and another two small screens coating at one time, please feel free to get more details from us.
