OEE W-446 triplex Mud pump
Product Quick Detail
- Place Of Origin: China
- oee.info@china-ck.com
- Packaging
- 1
- Delivery
- 1 Day
Specifications
OEE W446 triplex mud pump can 100% interchangeable with Emsco F500 triplex mud pump. It has small volume, low HP, and can fit small diesel engine. It can drill Well below the 3000 meters.
Rated input power: 328KW/440HP
Rated Stroke 320 stroke per minute 320spm
Stroke :152.4mm 6”
Gear Ratio: 4.578:1
Max. operating pressure: 35Mpa
Valve over valve: API4#
Dia. of Suction manifold: 6” 150# flange
Dia. of Discharge manifold: 3” 900#flange
Dia. pinion shaft: 95.25 3.75”
Key: 22.174x15.9mm
Dimension not including base: 2479x1219x1103mm
Weight : 4463kgs
Further information or quote, please contact below sales:
Jessie Ji
Sales Manager
Jinan Tianwei Innovation Oilfield Equipment Enterprise (OEE)
Jinding International Trade Development Ltd. (ITD)
Website: ww.china-ck.com
E-mail: oee.info (at) china-ck.com
Skype: jessie.neverland
Main: +86.531.6781.1566
Fax: +86.531.6781.1577
- Country: China (Mainland)
- Business Type:
- Market:
- Founded Year:2001
- Address:Shunshi Road,Jinan,Shandong,China
- Contact:Jessie Ji
