GDJ-II Transformer Oil Dielectric Strength Tester
Product Quick Detail
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
II.Functions:
1 Breakdown test of user-defined
2 Proof test
3 Calibration interface for customers
4 Result print
III.Technique index:
1 Output voltage: AC 0~80KV
2 Rate of voltage rise: 2KV/s±10%
3 Measuring precision: 3%RDG+0.3%FS
4 Test times setting: 1-9
5 Mixing time setting: 0~99 second
6 Waiting time setting: 0-9 minute 59second
7 Maximum storage capacity: 100 groups of test data
8 Test standards: IEC60156
9 Display: LED
10 Rated power supply: AC 220V±10% 50/60Hz
11 Environment temperatures: 0-50°C
12 Relative humidity ≤80%RH
13 Size: 420mm´325mm´300mm
14 Weight: 28kg
- Country: China (Mainland)
- Business Type:
- Market:Africa,Americas,Middle East,Oceania,Asia
- Founded Year:2009
- Address:NanPing
- Contact:Rita Lee
