38.1mm 1 1/2“ steel ball
Product Quick Detail
- Minimum Order
- 1 ton
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
15.875-80.00 mm G10-G60 chrome steel ball
2.General specification
| GB/T 308-2002&ISO3290 Standard | |||||||||||||
| | VDWS | Sph | Ra | VDWL | VDWA | IG;ST | | | | ||||
| Grad | Ball | Sphericity | Surface | Lot | variation | Soring Intervall | Allowable Ball Gauge Deviation | Subgauge Interval | Ball Subgauge | ||||
| variation | roughness | variation | |||||||||||
| | |||||||||||||
| | max. | max. | max. | max. | max. | max. | M | N | P | max. | M | N | P |
| G10 | 0,25 | 0,25 | 0,02 | 0,5 | -- | 1 | -9...-1 | 0 | +1...+9 | 0.2 | -0.4,-0.2 | 0 | +0.2,+0.4 |
| G16 | 0,4 | 0,4 | 0,025 | 0,8 | -- | 2 | -10...-2 | 0 | +2...+10 | 0.4 | -0.8,-0.4 | 0 | +0.4,+0.8 |
| G20 | 0,5 | 0,5 | 0,032 | 1 | -- | 2 | -10...-2 | 0 | +2...+10 | 0.4 | -0.8,-0.4 | 0 | +0.4,+0.8 |
| G24 | 0.6 | 0.6 | 0.04 | 1.2 | -- | 2 | -12...-2 | 0 | +2...+12 | 0.4 | -0.8,-0.4 | 0 | +0.4,+0.8 |
| G28 | 0,7 | 0,7 | 0,05 | 1,4 | -- | 2 | -12...-2 | 0 | +2...+12 | 0.4 | -0.8,-0.4 | 0 | +0.4,+0.8 |
| G40 | 1 | 1 | 0,06 | 2 | -- | 4 | -16...-4 | 0 | +4...+16 | 0.8 | -1.6,-0.8 | 0 | +0.8,+1.6 |
| G60 | 1.5 | 1.5 | 0.08 | 3 | -- | 6 | -18...-6 | 0 | +6...+18 | 1.2 | -2.4,-1.2 | 0 | +1.2.+2.4 |
4.Applications:
the chrome steel balls we produced are mainly applied in slewing ring bearing for wind turbines, such as single/double row ball bearing, single cross roller bearing, three roller bearing, double row angular contact ball bearing
5.Quality inspection
6. Eddy-current test machine
7. Packing
Packing: Paper Cartons & Wooden Pallet ;
Note: for 45mm balls, 50pcs/ctn,36ctn/pallet,1800pcs/pallet;
for 50mm balls, 50pcs/ctn,30ctn/pallet,1500pcs/pallet;
for 60mm balls, 30pcs/ctn,30ctn/pallet,900pcs/pallet;
8. Certificates: ISO 9001 & SGS
- Country:
- Business Type:
- Market:
- Founded Year:
- Address:
- Contact:amy zhang
