Dial size
|
40mm, 50mm, 65mm, 80mm, 100mm, 150mm & 250mm
|
|
Accuracy
|
+ 2% of f.s.d.
|
|
Bourdon Tube
|
Brass / Phosphor Bronze / S.S. 316
|
|
Movement
|
Brass / S.S. 304
|
|
Socket
|
Brass/S.S. 316
|
|
Case
|
Mild Steel / S.S. 304
|
|
Mounting
|
Direct with bottom entry / Direct with back entry / Flush Panel with back entry (Three hole panel or bracket type) / Surface with bottom entry
|
|
Thread Connection
|
1/8", 1/4", 3/8", 1/2" BSP/BSPT7 NPT (M)
|
|
Window
|
Glass / Polycarbonate.
|
|
Joints
|
S.S. Bourdon tube tip and the socket ends are ARGON ARC WELDED and phosphor bronze bourdon tubes are silver brazed / soldered. Bourdon tubes are heat-treated and stress relieved.
|
