Cells Per Unit
|
6
|
|
Voltage Per Unit
|
12
|
|
Capacity
|
100ah@20hrs-rate to 1.75v per cell @25℃/77°F
|
|
Approx Weight
|
29.0kg (Tolerance±1.5% )
|
|
Max.Discharge Current
|
1000A (5sec)
|
|
Internal Resistance
|
Approx 5.6mΩ
|
|
Operation Temp.Range
|
Discharge: -15-50℃ (5-122°F)
|
|
Charge: 0-40℃ (32-104°F)
|
|
Storage: -15-40℃ (5-104°F)
|
|
Nominal Operating Temp.Range
|
25±3℃ (77±5°F)
|
|
Float Charging Voltage
|
13.5V-13.8V (25℃/77°F) Coefficient:20mv/℃ (No limit on Initial Charging Current)
|
|
Recommended Maximum Charging Current
|
35A
|
|
Equalization and Cycle Service
|
14.4V-14.8V (25℃/77°F) Coefficient:30mv/℃ (Initial charging current less than 16.5A)
|
|
Self Discharge
|
RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for more than 6 months at 25℃. Self-discharge ratio less than 3% per month at
25℃. Please charge batteries before using.
|
|
Terminal
|
T5 or F7
|
|
Container material
|
ABS UL94-HB,UL94-V0 Optional
|
