Type
|
Specification
|
|
Nominal Voltage
|
12v(6cells)
|
|
Nominal Capacity
|
200ah (10hrs, 25℃/77°F)
|
|
170ah (5hrs, 25℃/77°F)
|
|
120ah (1hrs, 25℃/77°F)
|
|
Dimension
|
Length：522±2mm
|
|
Width：239±2mm
|
|
Container Height：218±2mm
|
|
Total Height(with Terminal):224±3mm
|
|
Approx Weight
|
61.0kg
|
|
Terminal
|
T5 or F7
|
|
Container material
|
ABS
|
|
Max.Discharge Current
|
2000A(5s)
|
|
Internal Resistance
|
Approx 3.2mΩ
|
|
Operation Temp.Range
|
Discharge:-15-50℃(5-122°F)
|
|
Charge: 0-40℃(32-104°F)
|
|
Storage: -15-40℃(5-104°F)
|
|
Nominal Operating Temp.Range
|
25±3℃(77±5°F)
|
|
Cycle Use
|
14.4V-14.8V(25℃/77°F) Coefficient:30mv/℃ (Initial charging current less than 16.5A)
|
|
Standby Use
|
13.5V-13.8V(25℃/77°F) Coefficient:20mv/℃ (No limit on Initial Charging Current)
|
|
Capacity affected by Temp.
|
103% 40℃(104°F)
|
|
100% 25℃(77°F)
|
|
86% 0℃(32°F)
|
