pharmaceutical vibrating screen

Features and Functions
1.The outlet can be adjusted at any angle,and it is easy to replace the screen
2.The rubber ball device can reduce the changce of jam on the screen
3.Easy to operate, impurities and coarse materials can be discharged automatically
4.Rotary Vibrating Screen has Good sealing property. Frame have a dedicated connection with rubber, fastening with a locking band.
Work principle
vibrating sieve uses upright motor as the source of vibration, equipped eccentricity hammer on the both sides of motor, changed circumrotate to level, upright anticline movement, then pass these three movements to the surface of the screen. Adjust the phase angle on the both sides of the top and bottom changing the movement orbits in the surface screen.
Technical parameters

Material Proportion Mesh Model Processing capacity
Chinese medicine powder 0.8 80 DYZ-800-1S 550 kg/h

Material Proportion Mesh Model Processing capacity
Chinese medicine liquid 0.9 150 DYZ-1000-1S 3000 kg/h

Material Proportion Mesh Model Processing capacity
Granule medicine 0.8 12 DYZ-1000-1S 2500 kg/h

Material Proportion Mesh Model Processing capacity
Western medicine powder 0.6 80 DYZ-1200-1S 400 kg/h

Material Proportion Mesh Model Processing capacity
Medicine intermediate 0.6 120 DYZ-1200-1S 300 kg/h

Material Proportion Mesh Model Processing capacity
Extractive 1.1 325 DYZ-1200-1S 1100 kg/h

Material Proportion Mesh Model Processing capacity
Medicine 0.7 20、80 DYZ-800-2S 800 kg/h

Material Proportion Mesh Model Processing capacity
Oral liquid 1 250 DYZ-1000-1S 2000 kg/h
