impact crusher

Impact crusher features:
1.Large inlet,high crushing chamber,meet the material hardness,degree block,less powder products.
2.Convenient to adjust to the space between counter board and plate hammer,control the discharge size effectively ,good particle shape.
3.Compact structure,strong rigidity of the machine,the rotor has a large moment of inertia.
4.High chrome hammer,resist compact,resist wear and tear,big impact.
5.Complete crushing functions,efficient production,less parts are wear and tear.high intregated benefits.
6.Reasonable design of leveling plate making the finished material finer and cubic-shaped without internal cracks.
7.Hydraulic start-up which is convenient for maintenance and replacement of wearing parts.
8.New anti-abrasive material which prolong service life of impact hammer, impact plate and liner.
Impact crusher working principle:
When impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where installed the hammers with high-tech raw material. When the crushed materials get into the impact crusher inner space where the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being recrushed. The materials from large to small all to be crushed at the impact crusher chamber repeatedly. The process won't stop till the materials in the impact crusher are crushed to the required size and then discharged from outlet.
Impact crusher application:
PF series of impact crusher is widely applied in mining, transportation, energy, Construction and chemical industry. Impact crushers are ideal choice for crushing and screening. Hard rock which granularity is less than 60-300mm can be processed, it more suitable for processing granite, limestone, bank gravel, The granularity of 80% finished products is less than 30mm.
Technical parameters
Model Specification(mm) Feeding size(mm) Max feed size(mm) Capacity(t/h) Motor power(kw) Weight(kg)

PF-0607 644*740 320*770 100 10-20 30 10216
PF-0807 850*700 400*730 300 15-30 30-45 11138
PF-1008 1000*800 400*830 300 30-50 37-55 12206
PF-1010 1010*1050 400*1080 350 50-80 55-75 13138
PF-1210 1250*1050 400*1080 350 70-120 110-132 15200
