Wire Mesh Cable Tray Accessory for Easy and Fast Installation
Accessories of wire mesh cable tray
We can supply all kinds of wire mesh cable tray accessories, they can be used to connect the cable trays, installed onto ceilings, walls and other places. Different accessories can ensure the stability and flexibility of cable trays. The accessories are supplied along with cable trays and they can be sold independently.
Connection system.
There are all kinds of accessories to connect the neighbor cable trays, including the straight cable trays, corner cable trays, horizontal or vertical cable trays, they can make the connection firm and solid and ensure the high strength of the cable tray.
Coupler
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: diameter from 3.5 mm to 6.0 mm.
- Component: top and bottom, M6 bolts and nuts.
- Application: straight sections and make bends.
- Features: wide application and high strength.
Strengthening bar
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: diameter from 3.5 mm to 6 mm.
- Component: bar, top and bottom, M6 bolts and nuts.
- Application: splices straight sections.
- Feature: high strength and firm.
Corner strength bar
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: diameter from 3.5 mm to 6 mm.
- Component: bar, top and bottom, M6 bolts and nuts.
- Application: T and cross connectors.
- Feature: high strength and flexible.
Fast fix splicer
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: diameter from 4.5 mm to 5.5 mm.
- Component: 1 splicer.
- Application: connect straight section.
- Feature: boltless and fast installation.
Boltless coupler
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: diameter from 4.5 mm to 5.5 mm.
- Component: 1 coupler.
- Application: connect bottom straight sections.
- Features: boltless and fast installation.
Supporting system.
Supporting system is widely used in the installation of wire mesh cable tray including, wall installation, hanging installation and ground installation. The various supporting accessories can make the installation easy and fast.
L wall bracket
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: all wire mesh cable tray.
- Component: a L bracket and expansion screws.
- Application: wall installation.
- Features:
- Large distance to the wall.
- Multi-layer wire mesh cable installation.
Cantilever wall bracket
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: width from 300 mm to 900 mm.
- Component: cantilever wall bracket, expansion screws.
- Application: support cable trays on wall.
- Features: strong support for wide trays.
Spider bracket
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: width from 50 mm to 200 mm.
- Component: spider bracket, expansion screws.
- Application: support trays on side walls.
- Features: easy installation and low cost.
Ω bar
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: most wire mesh cable tray.
- Component: a Ω bar, rods, bolts and nuts.
- Application: used for ceiling mounting.
M shape bar
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: most wire mesh cable tray.
- Component: a M shaped bar, rods, bolts and nuts.
- Application: hanging wire mesh cable tray under ceiling.
C channel
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Component: C channel, coupler, rods.
- Application: ceiling mounting.
Hanging hooks
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: less than 300 mm wire mesh cable tray.
- Component: hanging hooks, rods, bolts and nuts.
- Application: hanging wire mesh cable tray under ceiling.
50 tray holder
- Material: EZ steel, HDG steel, PC steel, SS304, SS316, SS316L.
- Fit for: 50 mm wide wire mesh cable tray only.
- Component: 50 tray holder, rods.
- Application: support cable tray under ceiling.
