TECHNICAL SPECIFICATION | |||
Model | LS20T/610H/V-FSG-B | LS26T/610H/V-FSG-B | LS30T/610H/V-FSG-B |
Description | Gasoline engine driven, horizontal ,4 way axe head . | ||
Motive power | 6.5HP | 6.5HP | 9HP |
Max. split force | 20tons | 26tons | 30tons |
Max split size | Φ500mm X 610mm(L) | ||
Hydraulic oil | 18L | ||
Oil cylinder diameter | 4inch | 4.5inch | 5inch |
Travel time | 13seconds | ||
Pump | 11GPM | 11GPM | 16GPM |
Starting System | Recoil | ||
Outline dimensins | 2550*1130*1280 | ||
Packing dimensions | 2000L*900W*565H mm | ||
N.W./ G.W. | 173/184kgs | 176/187kgs | 190/201kgs |
Packing Method | 1pc./ steel pallet | ||
Container Quantity |
24pcs. for 20'FCL
http://www.huahengjx.com |
