TP20AC220S12W 20W 4KV Isolation Wide Input AC/DC Converters

Minimum Order
100
Place Of Origin
CHINA
FOB Price
USD $9.50 / Piece
Packaging
30/TUBE
Delivery
15 Days
The rated output power of TP20AC series is 20W with wide input voltage range, for both AC input and DC input application. High reliability, precision, large power density, ultra-small size, no external heat sink required, stable output voltage and etc, with over current protection, EMI filter circuit, the rectifier filter circuit, 4000V isolation voltage, short circuit, overload, internal thermal protection, Widely used in telecommunications, industrial control, instrument, data acquisition, signal control and other electronic systems.

Part Number Input Voltage Output
Rated
Range values Voltage(VDC) Current(A)
(VAC) (VDC)
TP20AC220S05W 85-300 110-370 5 4.0
TP20AC220S09W 85-300 110-370 9 2.22
TP20AC220S12W 85-300 110-370 12 1.66
TP20AC220S15W 85-300 110-370 15 1.33
TP20AC220S24W 85-300 110-370 24 0.83
