Jiangsu Fanqun LPG High-speed Centrifuge Spray Dryer

Jiangsu Fanqun LPG High-speed Centrifuge Spray Dryer - Jiangsu Fanqun Spray Dryer - Jiangsu Fanqun Drying Equipment

*General Descriptions:

LPG series high-speed centrifuge spray dryer is a special equipment and is suitable for drying emulsion, suspending liquid, liquor and so on. Particularly it has unique advantages for drying polymers and resins; dyestuff and pigment; ceramics; glass; derust agent; pesticide; carbohydrate, dairy products; detergent and surfactant; fertilizer, organic compound, inorganic compound and so on.

*Principle of Work:

Air is turned into hot air through air filter and heater and enters into hot air distributor at the top of dry chamber and then enters into dry chamber spirally and evenly. At the same time, liquid of raw material is sent to centrifugal Spray at the top of dry chamber pumped by pump through filter in which liquid of raw material Spray ting droplets. Air and liquid of raw material flow and contact each other fully. The moisture vaporizes rapidly. Liquid of raw material is dried into the finished product in a short time. The finished product is discharged through cyclone separator at the bottom of drier. The wasted air is exhausted through fan.

*Features:

Its dry speed is very high. In general, it needs 5-15 seconds. It has a feature of momentary dry.

Because raw material can be dried momentarily, the dryer is especially suitable for drying thermal sensitive raw materials. It can maintain color, smell and taste of raw materials.

Its operation is stable and simple. Its regulation and control is very convenient. And the continuous controlled production is easy to realize.

The distribution, fluidity and solubility of product are good.

Notes: The evaporated amount of moisture is related to characteristics of raw material and outlet temperature of hot air. The curve of moisture evaporation is shown in above Fig when the outlet temperature is 90. (For reference when you choose Model). With the unceasing renewal of products, the relevant parameters are changed constantly and can't be provided in advance!

*About Jiangsu Fanqun Spray Dryer

Spray Drying is the most economical method of evaporation to reduce a liquid feed to solid powder particles. It is used in all areas of industry, many products requiring specialist designs and finishes to maximize the efficiency or sanitary needs of that particular process. We provide three models of Spray Drying, including ZLPG Spray Dryer, PGL Spray Dry Granulator, LPG High-speed Centrifuge Spray Dryer, etc.
