Description
Prairie Fence also named prairie fence and field fence , are made of hot-dipped zinc coated steel wire, offer high strength and tensile strength, provide safety fencing against fierce striking of cattle, horse or goats.
Height: 0.8m~2.4m
Wire Diameter: 2.0mm-2.5mm
Applications: Horse, Cow Fence
Features: Easily Assembled, Waterproof, Eco Friendly, Rot Pr
Categories: Hot-dip galvanized frairie fence, Electric galvanized frairie fence
Transport Package: in Pallet or in Bulk
Specification
um | Specification mesh | Gross Weight | Wire Diameter | In silk | Volume diameter (mm) | |
(kg) | (mm) | Dia | ||||
Type | Specification | (mm) | ||||
1 | 7/150/813/50 | 102+114+127+140+152+178 | 19.3 | 2.5 | 2 | 280 |
2 | 8/150/813/50 | 89(75)+89+102+114+127+140+152 | 20.8 | 2.5 | 2 | 280 |
3 | 8/150/902/50 | 89+102+114+127+140+152+178 | 21.6 | 2.5 | 2 | 280 |
4 | 8/150/1016/50 | 102+114+127+140+152+178+203 | 22.6 | 2.5 | 2 | 280 |
5 | 8/150/1143/50 | 114+127+140+152+178+203+229 | 23.6 | 2.5 | 2 | 280 |
6 | 9/150/991/50 | 89(75)+89+102+114+127+140+152+178 | 23.9 | 2.5 | 2 | 280 |
7 | 9/150/1245/50 | 102+114+127+140+152+178+203+229 | 26 | 2.5 | 2 | 280 |
8 | 10/150/1194/50 | 89(75)+89+102+114+127+140+152+178+203 | 27.3 | 2.5 | 2 | 280 |
9 | 10/150/1334/50 | 89+102+114+127+140+152+178+203+229 | 28.4 | 2.5 | 2 | 280 |
10 | 11/150/1422/50 | 89(75)+89+102+114+127+140+152+178+203+229 | 30.8 | 2.5 | 2 | 280 |
Features
Our field fence have innovative and firm structure,flat surface,uniform opening and good integration.This product offers good flexibility;good pressure resistance,corrosion resistance and weather resistance properties and can serve for a very long time. Even the cut pieces will not deform under pressure.It has excellent corrosion resistance and anti-oxidizing property.our field fence are firm forever once installed and make the best materials for protecting grassland, forestry, highway and environments.
Applications
It is widely used in lawn and breed aquatics for all such purposes as enclosures, decoration, machine defend, etc.
