Mainly Features
1. Inbuilt ARM® Cortex™-M4 32 Bit RISC Core MCU; 2. Quadband 850/900/1800/1900Mhz GSM GPRS Module inside, 3G WCDMA / CDMA2000 Modules are optional; 3. Widely Rated voltage range, 9~36VDC, Inbuilt large capacity rechargeable backup battery; 4. Large internal memory to save up to 3500 historical records, USB port for configuration, upgrade firmware and export records; 5. Inbuilt industrial ISM Band 433Mhz Radio Frequency Half duplex communication module, distance up to 2~5Km; 6. Supports maximum 50 wireless Data Acquisition Modules, will alert users by SMS once the wireless DAM connect failure to ensure the monitoring working properly; 7. Supports maximum 400 wireless distributed I/O endpoints; 8. 2 solid relay outputs, rated capacity is 5A/30VDC,5A/250VAC; 9. 4 digital inputs, compatible to dry contact or wet contact inputs. Logic level: 0~0. 5V or short circuit treated as close, +3~30V or open circuits treated as open; 10. 1 temperature & humidity sensor input for monitoring onsite environment, the sensor model is AM2301, Measures temperatures from -40-80°C,0.5°C accuracy, Relative Humidity from 0-99RH%, accuracy is 3%; 11. 1 RS485 serial port (Optional: RS232) for Modbus RTU Slave to SCADA or data transparent transmission;. 12. I/O ports with opto-isolated, RS232/485/RJ45 with 15KV ESD protection; 13. Supports Modbus TCP,TCP/IP protocol, Definition Protocol and transparent transmission over GPRS/3G/ Ethernet network; 14. Automatically resend the data while GPRS/3G/Ethernet communication interrupt or failure, GPRS/3G failure will alert by SMS text to users; 15. Supports remotely restart the RTU, and configure& operate it by SMS commands remotely; 16. Supports over voltage protection and phase-reversal protection, provide DC power sources for external device to save wiring cost; 17. 10 SMS Alert and auto dial numbers for receiving alarm message, can program to receive specified alarm message. |
BL100 is a cost-effective industrial IOT gateway based on cellular network. It supports Modbus RTU, Modbus TCP, MQTT, Alibaba Cloud, HUAWEI Cloud, King Pigeon Cloud, custom platform and transparent data transmission. Users can connect it to third-party server, cloud platform ...
S281 LoRa gateway is data acquisition device based on Lora, 4G and Ethernet communication technologies. One LoRa gateway can collect data from 50 wireless Lora nodes, and the communication distance can reach 2000 meters. It is an optimal solution for data collection within the ...
S475 is industrial 4G RTU that supports 4G and ethernet communication, SMS and MQTT protocol. It is compatible with Huawei cloud, Alibaba cloud and other clould platform including customized cloud platform. It has two RS485, eight DI, four Relay output, six AI and one ...
