Item | Reference Scope |
DC Power supply | Standard adapter: DC 12V/1.5A Range 9-36VDC |
Power consumption | Standby:12V/70mA; Working Max.: 12V/300mA |
GSM Frequency | 850/900/1800/1900Mhz |
3G/4G/NB-Iot | Optional: WCDMA/TDD-LTE/FDD-LTE/NB-IoT |
TCP/IP stack | TCP,UDP |
SIM interface | Supporting Dual 3V SIM Card |
External antenna | SMA Antenna interface, 50 Ohm, Gain: 3dB |
Serial Interfaces | 1 USB Port |
Protocols | SMS, GPRS UDP,TCP, Modbus RTU, Modbus TCP and more equipment protocols can be added according to requirements. |
Ethernet | 1 RJ45 Ethernet port for connect internet, WAN or LAN. |
RS485 | 2 RS485, Support Transparent transmission and Modbus RTU Slave, Modbus RTU Master. |
Temp.&Hum Inputs | Temperature range: -40°C to +80°C, Humidity Range: 0~100%RH; |
Power Outputs | 1 Port, for external device; |
Mapping Registers | Max.320 |
Memory Capacity | Internal 8G SD card inside, can save the data for 100000events. |
Backup Battery | 3.7V 1200mAH |
Temperature range | -10-+70 °C |
Humidity range | Relative humidity 95% (condensation free) |
Exterior dimension | 70mm*88mm*30mm |
Net Weight | 500g |
