ZGB Ash Slurry Pump

ZGB Ash Slurry Pump

Main Specifications

Size: 65mm-300mm

Capacity: 50-1800 m3/h

Head: 50-90m

Material: Hi-chromium metal liner, or Rubber liner

Seal: Expeller seal combined with packing and Mechanical seal

Pump Features

1. The ZGB(P) pumps are horizontal single-stage ,single-suction ,cantilever ,double-casing , centrifugal slurry pump .This series pumps are large capacity,high head and multi-stage. The wet parts of ZGB and ZGBP pump at the same outlet diameter can be interchangeable. Their outline installation dimensions are one and the same.

2. The drive part of this series slurry pump: horizontal split frame with oil lubrication and two sets of water cooling systems inside and outside has been adopted.

3. The pumps are wide passage , non-clogging and good performance of NPSH. The pumps expeller seal combined with packing seal and mechanical seal have be adopted to guarantee the slurry from leakage

Pump Code Explanation

Applications

Series ZGB(P) slurry pumps are suitable for conveying abrasive or corrosive slag slurry in the mining, petrochemical, building material, electric power, metallurgy, coal industries, etc. especially plant ash.

Pump Structure

Type ZGB Slurry Pump

1. front liner insert; 2. impeller; 3. volute; 4. frame body; 5. shaft; 6. adjusting screw(b);

7. adjusting screw(a); 8. adjusting cover; 9. expeller ring; 10. expeller; 11. back liner insert;

12. pump body; 13. pump cover;Type ZGBP Slurry Pump

1. front liner insert; 2. impeller; 3. volute; 4. frame body; 5. shaft; 6. mechanical seal; 7. sealing box; 8. back liner insert; 9. pump body; 10. pump cover;

Pump Parameter
