Waterproof metal cable glands IP68

SHBDM-27 Metal waterproof cable gland

Specification

Main body is made of brass,nickel planted or stainless steel,Claw is made of PA,seal and o-ring is made of NBR.

Approvals：CE

Protection level:IP68(Tighten the glands with o-ring)

Ambient temperature:Static from -40℃ to 100℃,short up to 120℃

Dynamic from -20℃ to 80℃,short up to 100℃

Thread length:Standard thread type is used for the equipment which has inner thread or for the thin board.Long thread type is used for the thin board.Long thread type is used for the thick board.

Function:Extremely easy installation,simply insert cable through the assembled gland and tighten gland lock nut until cable is secured.These cable glands are designed to withstand water,dust,salt,acid-base,alcohol,oil and common solvent.

Usage:Waterproof brass cable gland is the product of form a complete set of the cable,connector cable can be locked,the other end can access devices on the box body,also can choose thread access according to th import and export for internal thread electric devices.

Size:M8-M115,G1/2-G4,NPT1/2-NPT4

Customization is accepted!!
