This Aluminized Kevlar Heat Barrier is made from aramid 1414 and aluminum mylar finish.
This heat shield barrier is capable of reflecting 90 percent of radiant heat. Face the aluminized side toward the source of radiant heat to shield heat away.
Feature
Aramid heat barrier can withstand up to 3000 degrees F of radiant heat and can withstand direct contact up to 800 degrees F.
Application
Use aramid heat barrier on Firewall, floor pan, under cab (above: muffler, catalytic convertor, DPF, exhaust system), fuel cel.
Specifications
Datasheet | |
Material | Aluminum, aramid |
Continuous Temperature | 1100 °F |
Melt Temperature | 3000 °F |
Standard Thickness | 1.5mm |
Length | MAX 50 meter/roll |
Color | Silver |
Cutting Tool | Scissor |
Part Number | Description |
301212 | 12 in × 12 in |
301224 | 12 in × 24 in |
301300 | 12 in × 50 in |
301818 | 18 in × 18 in |
302424 | 24 in × 24 in |
302448 | 24 in × 48 in |
302640 | 26 in × 40 in |
303658 | 36 in × 58 in |
304036 | 40 in × 36 in |
304050 | 40 in × 50 in |
304046M | 40 in × 164 ft |
Notes:
Special size and color upon request.
MaterialStructure: PET/AL/PE PET/AL/PA/PE PE/AL/PA/PE PE/AL/PET/PE oras customers\' requirements. Thickness: 60---180microns Size: It can be made in any sizes according to customer\'s requirements. Function: Moisture barrier, oxygen barrier and UV protection. Specification: ...
Aluminized Titanium Heat Shield Mat is made by heat reflective aluminum and volcanic rock fiber. This shield is capable of reflecting 90% of radiant heat. Face the aluminized side toward the source of radiant heat to shield heat away. Feature Aluminized radiant heat barrier can ...
